Mother/Fetal Monitor PDJ-800F

Single or Twins Ultrasound transducer, Data Graph and Trend Table Review of both mother and fetal, Built-in thermal printer, has a Programmable alarms, Built-in Network capability for connect with central monitoring software. All the colors and looks or the parameters can be customized. Multi-face views, select focus on mother or fetal.

Compare

Description

Product Description

Features:

Single or Twins Ultrasound transducer

Data Graph and Trend Table Review of both mother and fetal

Built-in thermal printer

Programmable alarms

Built-in Network capability for connect with central monitoring software

All the colors and looks or the parameters can be customized

Multi-face views, select focus on mother or fetal

Storage of patient information and data

Product Specifications:

Performance Specifications Display: 8.4″ Color TFT
Resolution: 640×480
Display Mode: Standard View, Fetal View, Mother View
Indicator: Power indicator light, Alarm sound
Interface: Socket for connecting fetal FHR, TOCO, and Fetal Movement
Sensor Socket for connecting mother ECG, NIBP and SPO2 sensor.
Net Socket(RJ45) for communication cable with Central Monitoring Station Software.
Power Supply: AC 100 ~ 240V, 50/60Hz, Power < 60VA
Trend Graph: Resolution from 1s, 5s, 10s. Maximum time 96 hours.
Trend Table: Resolution from 1s, 5s, 10s. Review up to 1000 items.
Alarm: Adjustable High and Low limits. Three level audible and visual alarm.
User Configuration: All the color of parameters and waves can be set according to user willing.
Technical specifications Meet the requirement of IEC60601 series
Degree of Protection: BF
Type of Protection: Class II with internal electric power supply
Dimension: 92(W)x82(H)x22(D)mm
Weight: 136g(with battery)
Operation Environment Temperature: 0°C~ +40°C
Humidity: 15% ~ 95%
Storage Environment Temperature: -20°C~ +60°C
Humidity: 10% ~ 95%
Patient Range: Pregnant Adult
FHR Ultrasound Frequency: 2MHz
Range: 50 ~ 210 bpm
Resolution: 1bmp
Accuracy: ±2bmp
FETAL MOVEMENT Manual fetal movement mark
SPO2 Measurement Range: 0 ~ 100%
Resolution: 1%
Accuracy: ±2%(70%~100%, Adult/Pediatric, non-motion)
±3%(70%~100%, Neonate, non-motion)0% ~ 69% unspecified
Alarm Range: 0% ~ 100%
Refreshing Rate: 1s
Pulse Rate Measurement Range: 25 ~ 250 bpm
Resolution: 1bpm
Accuracy: ±3 bpm (non-motion)
Alarm Range: 25 ~ 250 bmp
Refreshing Rate: 1s
ECG Lead mode: 3-lead or 5-lead
Lead selection: I, II, III, AVR, AVL, AVF, V
HR range: 15 ~ 300 bpm
ECG Waveform: 2 channels
Accuracy: ±2bpm or ±2%, which is greater
S-T segment detection range: -2.0mv ~ +2.0mv
Arrhythmia analysis: 13 kinds of arrhythmia
Alarm Range: 15 ~ 300 bpm
NIBP Method: Oscillometry
Mode: Manual/Auto/Continuous
Measurement Range: 25 ~ 260mmHg
Auto Measure Interval: 5, 10, 15, 30, 45, 60, 90 minutes
Resolution: 1mmHg
Overpressure Protection: 300mmHg
Alarm range: 25 ~260mmHg
