REF: MEN-2026-0543
Intensive Care Unit
12 Channel ECG EKG (Electrocardiograph) Machine
Sold & Shipped By
Official Store
Price on Request
Product Code MEN-2026-0543
Condition New
Availability In Stock
Warranty
Sub-Category Electrocadiology
1.Portable and delicate design, easy to operate
2.Accurate pulse pace identification function
3.High accuracy digital filter, automatic baseline adjustment
4.Working modes: Manual, Automatic, Arrhythmia Analysis, Storage
5.215mm, 12 channel format recording, excellent automatic interpretation
6.800×480 graphic 7 inch color LCD to simultaneously display ECG information
7.Alphanumeric keyboard to operate, very convenient to use
8.250 patient cases storage ( SD card storage is optional )
9.Detailed patient information record
10.Adapt to 110-230V,50/60Hz power supply. Built-in rechargeable
11.Li-ion battery continuously working for about 4 hours
12.USB / Rs232 communication port support USB storage, laser printer
13.printing and PC ECG software ( Optional )
2.Accurate pulse pace identification function
3.High accuracy digital filter, automatic baseline adjustment
4.Working modes: Manual, Automatic, Arrhythmia Analysis, Storage
5.215mm, 12 channel format recording, excellent automatic interpretation
6.800×480 graphic 7 inch color LCD to simultaneously display ECG information
7.Alphanumeric keyboard to operate, very convenient to use
8.250 patient cases storage ( SD card storage is optional )
9.Detailed patient information record
10.Adapt to 110-230V,50/60Hz power supply. Built-in rechargeable
11.Li-ion battery continuously working for about 4 hours
12.USB / Rs232 communication port support USB storage, laser printer
13.printing and PC ECG software ( Optional )
Lead Standard 12 leads Time constant ≥3.2s
Lead acquisition 12bit/1000Hz (synchronously 12 leads) Frequency response 0.05~160Hz(-3db)
Work mode Man / Auto/Analysis/Storage Noise level <15μVp-p
Filter AC Filter : 50Hz / 60Hz Inter-channel Interference ≤0.5mm
EMG Filter : 25Hz / 45Hz Sensitivity 2.5,5,10,20, 40, Auto (mm/mV)
Anti-Drift Filter : 0.15Hz (Adaptive) Recording mode 3ch+++, 6ch, 6ch+,12ch
CMMR ≥120dB (with AC FILTER) Default Man. Mode is 3ch+++ format
Input circuit Floating; Protection circuit against Default Auto. Mode is 12ch format
Defibrillator effect Paper speed 6.25,12.5,25,50mm/s(±3%)
Input Impedance ≥50MΩ Paper 215mm *20m Roll or 210*140mm folder paper
Input circuit current ≤0.05μA Communication RS232/ USB port ( optional)
Patient current leakage <10μA Power Supply AC 110-230V(±10%),50/60Hz(±1Hz),60VA
Calibrating voltage 1mV±2% DC Built-in rechargeable battery,14.4V(4400mAh)
Voltage tolerance ≥±500mV Dimension/Weight 347mm×293mm×83mm/4.8Kg
Lead acquisition 12bit/1000Hz (synchronously 12 leads) Frequency response 0.05~160Hz(-3db)
Work mode Man / Auto/Analysis/Storage Noise level <15μVp-p
Filter AC Filter : 50Hz / 60Hz Inter-channel Interference ≤0.5mm
EMG Filter : 25Hz / 45Hz Sensitivity 2.5,5,10,20, 40, Auto (mm/mV)
Anti-Drift Filter : 0.15Hz (Adaptive) Recording mode 3ch+++, 6ch, 6ch+,12ch
CMMR ≥120dB (with AC FILTER) Default Man. Mode is 3ch+++ format
Input circuit Floating; Protection circuit against Default Auto. Mode is 12ch format
Defibrillator effect Paper speed 6.25,12.5,25,50mm/s(±3%)
Input Impedance ≥50MΩ Paper 215mm *20m Roll or 210*140mm folder paper
Input circuit current ≤0.05μA Communication RS232/ USB port ( optional)
Patient current leakage <10μA Power Supply AC 110-230V(±10%),50/60Hz(±1Hz),60VA
Calibrating voltage 1mV±2% DC Built-in rechargeable battery,14.4V(4400mAh)
Voltage tolerance ≥±500mV Dimension/Weight 347mm×293mm×83mm/4.8Kg
Medical Equipment Hospital Equipment 12 Channel ECG EKG (Electrocardiograph) Machine
Portable and delicate design, easy to operate
Accurate pulse pace identification function
High accuracy digital filter, automatic baseline adjustment
Working modes: Manual, Automatic, Arrhythmia Analysis, Storage
215mm, 12 channel format recording, excellent automatic interpretation
800×480 graphic 7 inch color LCD to simultaneously display ECG information
Alphanumeric keyboard to operate, very convenient to use.
