Physical
Dimension: 1350mm (H)*560mm (W) *620mm (D)
Weight: 85 kg
Display: 5.6 inch LCD screen
Casters: Four anti-static casters with diameter 100mm, the front two are with brakes
Electronic Specification
Power input: 100~240V, 50/60 HZ
Power Consumption: <= 50VA
Top light
Backlight at flowmeter
Pneumatic Specification
Pipeline : O2, N2O and Reserved O2
Yoke (optional) : 1 x O2, 1 x N2O
Pressure gauge : 2 for pipeline gas; 2 for cylinder gas (optional)
Flowmeter : O2 & N2O; Mechanical 4 tubes; O2 & N2O linkage and N2O cutoff system
O2 : 0~1L/Min, 1~10L/Min
N2O : 0~1L/Min, 1~10L/Min
O2 flush : 25-75L/min
Operational modes : Closed and Semi-closed circuit system
APL valve : 0,19~6KPa
Manual (Bag) / Mechanical ventilation switch : By-stable type, switch between manual/spontaneous ventilation and ventilator
ACGO connector : ISO 22mm OD and 15mm ID
Vaporizer
One or Dual positions
Mounting: Fixed or tool-free installation Selected manifold interlocks and isolates vaporizers
Agent type: Sevoflurane, Halothane, isoflurane and Enflurane
Filling type: Pour-fill, Easy-fill, Quick-fill or Key-fill
Compensation: Flow, pressure, and temperature compensation
Ventilator Specification
Type & Drive mode: Integrated Electronically-controlled pneumatically-driven ventilator
Patient: Pediatric and adult
Ventilation mode: IPPV, IPPB, SIGH, MAMUAL/Spontaneous
Tidal Volume: 50~1500ml
Frequency: 0~100bpm
I:E ratio: 1:10~10:1
Pmax: 8Kpa
Pmin:0~2Kpa
PEEP(optional): Mechanical type
Monitoring
Tidal volume: 0~2000ml
Pressure: -2~10Kpa
Frequency : 0~120bpm
Waveform : P-T
FiO2 (optional) : 21%~100%
Alarm
Upper airway pressure limit
Lower airway pressure limit

Advanced Control Technology, Classic Design Alloy Material, High Temperature Spray, High Quality & Technology ventilator, Patient type: Adult, pediatric. Driven mode: Pneumatic control electrical control Display: 4.2″ TFT color display Ventilation mode: IPPV, STANDBY, SIGH, Manual Tidal volume: 50mL to 1500mL Respiratory frequency: 6 to 60bpmI:E ratio: 1:1 to 1:4 Upper airway pressure limit: 1 to 8kPa Lower airway pressure limit: 0 to 2kPa Tidal volume: 50mL to 1500mL Silence time for alarm: ≤ 120s Monitoring parameters: Tidal volume, Respiratory frequency, Airway pressure Alarm parameters: Airway pressure limit, oxygen supply failure, Power supply failure Safety valve pressure limit: ≤ 6kPaPower supply: AC 220V ± 10%, 50Hz ± 1%.
