REF: MEN-2026-0453
Dental
DC3000 Dental Unit
Sold & Shipped By
Official Store
Price on Request
Product Code MEN-2026-0453
Condition New
Availability On request
Warranty
Sub-Category
1. Chair cushion made of soft vacuum memory cotton PU material, ergonomic for patient comfort
2. All-direction automatic control program with single-button operation
3. Side box can rotate 90°, providing more workspace for the assistant
4. No-screw fixation design allows for easy after-sales maintenance, saving time, money, and effort
2. All-direction automatic control program with single-button operation
3. Side box can rotate 90°, providing more workspace for the assistant
4. No-screw fixation design allows for easy after-sales maintenance, saving time, money, and effort
Power supply: AC220V/110V, 50/60Hz
2. Input power: 1200W
3. Fuse: RFl-20, Ф5×20, rated current 6.0A
4. Lights & Display:
5. Dental operatory light (cold light): AC12–24V / 6W–10W
6. X-ray film viewer: AC24V / 4W
7. Water supply thermostat: AC24V / 80W, temperature: 40℃ ± 5℃
8. Oral operatory light color temperature: ≤4500K
9. Dental operatory light intensity: 7000–42000 lux
10. Chair & Mechanical:
11. DC motor: DC24V / L3.8A
12. Minimum chair height: ≤50 cm
13. Maximum chair height: ≥75 cm
14. Load capacity of chair: ≤250 kg
15. Chair cushion length: <1.9 m
16. Load capacity of dental instrument tray: 1.5 kg
17. Size of dental chair unit: 155 × 105 × 125 cm
18. Packed weight: 250 kg
2. Input power: 1200W
3. Fuse: RFl-20, Ф5×20, rated current 6.0A
4. Lights & Display:
5. Dental operatory light (cold light): AC12–24V / 6W–10W
6. X-ray film viewer: AC24V / 4W
7. Water supply thermostat: AC24V / 80W, temperature: 40℃ ± 5℃
8. Oral operatory light color temperature: ≤4500K
9. Dental operatory light intensity: 7000–42000 lux
10. Chair & Mechanical:
11. DC motor: DC24V / L3.8A
12. Minimum chair height: ≤50 cm
13. Maximum chair height: ≥75 cm
14. Load capacity of chair: ≤250 kg
15. Chair cushion length: <1.9 m
16. Load capacity of dental instrument tray: 1.5 kg
17. Size of dental chair unit: 155 × 105 × 125 cm
18. Packed weight: 250 kg
Operation manuals are available upon request during delivery.
