REF: MEN-2026-0345
Opthalmology
Eye Auto Chart Projector; ACP-1000
Sold & Shipped By
Official Store
Price on Request
Product Code MEN-2026-0345
Condition New
Availability On request
Warranty
Sub-Category Chart Projector
Projection distance:1.5m ~ 6m, Projection magnification:30 x (at 5m), Projection size:330mm(W) x270mm(H) (at 5m), Chart:30 different patterns, Speed of chart conversion: One chart per 0.01~0.02s, Mask:1 open, 5 horizontal lines,8 vertical lines, 21 single letters, 1 red/green
Projection distance: 1.5m ~ 6m
Projection magnification 30 x (at 5m)
Projection size 330mm(W) x270mm(H) (at 5m)
Chart 30 different pattern
Speed of chart conversion One chart per 0.01~0.02s
Mask 1 open, 5 horizontal lines,8 vertical lines, 21 single letters, 1 red/green
speed of mask conversion One mask per 0.03s
Program 2 sets programs, each program contains up to 30 steps
Light source 12V,50W Halogen Lamp
Auto-off function After 10 minutes idle time.
Power source AC 220V ,50Hz or 110V, 60Hz
Power consumption 80W
Dimensions 300mm(L) x 230mm(W) x 240mm(H)
Net weight 6Kg
Accessories Remote control, Polarized metal screen, halogen lamp, polarized glasses, fuses(2), batteries(2)
Optional accessories Floor stand, wall stand
Projection magnification 30 x (at 5m)
Projection size 330mm(W) x270mm(H) (at 5m)
Chart 30 different pattern
Speed of chart conversion One chart per 0.01~0.02s
Mask 1 open, 5 horizontal lines,8 vertical lines, 21 single letters, 1 red/green
speed of mask conversion One mask per 0.03s
Program 2 sets programs, each program contains up to 30 steps
Light source 12V,50W Halogen Lamp
Auto-off function After 10 minutes idle time.
Power source AC 220V ,50Hz or 110V, 60Hz
Power consumption 80W
Dimensions 300mm(L) x 230mm(W) x 240mm(H)
Net weight 6Kg
Accessories Remote control, Polarized metal screen, halogen lamp, polarized glasses, fuses(2), batteries(2)
Optional accessories Floor stand, wall stand
Operation manuals are available upon request during delivery.
