Product name
Sp-400 Syringe Pump
Flow rate
50ml( 60ml ) syringe: 0.1 – 1500ml/h; 30ml syringe: 0.1 – 900ml/h; 20ml syringe: 0.1 – 600ml/h; 10ml syringe: 0.1 – 300ml/h; 5ml syringe: 0.1 – 150ml/h
Bolus rate
50ml( 60ml ) syringe: 100 – 1500ml/h; 30ml syringe: 100 – 900ml/h; 20ml syringe: 100 – 600ml/h; 10ml syringe: 100 – 300ml/h; 5ml syringe: 100 – 150ml/h
Infusion mode
Rate mode, Time mode, Dose mode, Intermittent infusion mode, TIVA mode, Drug library mode
KVO rate
0.1-2ml/h adjustable; default value:0.1 ml/h
Warranty
1 year
Syringe accuracy
±2%( after syringe correct calibration )
Volume to be infused
(VTBI)
0-1000ml
KVO rate
0.1-2ml/h adjustable; default value 0.1ml/h
History records
1600 records
Nurse call alarm
Optional
Volume infused
(∑)
0-9999.9 ml
WiFi
Optional
Power consumption
25VA
Occlusion pressure
(40-160)kPa
Computer interface
RS232 interface
Dimensions
300×130×125mm(L×W×H)
Classification
Class I, type CF
Net weight
1.8 kg
Waterproof level
IP×3
Alarm
Infusion completion, Empty, Occlusion, Near completion, Low battery, Syringe disengaged, No AC power supply, Battery exhausted, Malfunction etc.

Operation manuals are available upon request during delivery.
